Wireless Vibration Monitoring System

Wireless Vibration Monitoring System

Wireless Vibration Sensors

The SINUS/PCB Echo® Wireless Vibration Monitoring System can safely “look” at the machine’s health several times per day and provide data to your existing vibration monitoring system. The system allows the reliability-centered maintenance team to monitor more channels with fewer resources by eliminating the collection of vibration data on healthy machines. The system also allows measurements to be taken daily on machines in dangerous, remote and hard-to-reach locations. It’s been tested in a number of different types of plants including power, steel, food processing, paper, chemical and automotive.

A range of accelerometers and receivers are available

Echo® Wireless Vibration Sensor

• Frequency Band: 900 MHz ISM Band
• Number of RF Bands: 12
• RMS Velocity Frequency Range: (±3dB) 4 to 2300 Hz
• Velocity Range: 4 ips rms (101.6 mm/s rms)
• RMS Acceleration Frequency Range: (±3dB) 2200 to 15000 Hz

Echo® Wireless Vibration Sensor, Intrinsically Safe

• Frequency Band: 900 MHz ISM Band
• Number of RF Bands: 12
• RMS Velocity Frequency Range: (±3dB) 4 to 2300 Hz
• Velocity Range: 4 ips rms (101.6 mm/s rms)
• RMS Acceleration Frequency Range: (±3dB) 2200 to 15000 Hz

Echo® Receiver, 916 MHz

Echo® Wireless Receiver to be used in conjunction with Echo® Wireless Vibration Sensors (670A01) and EchoPlus® Wireless Junction Box (672A01).

• Frequency Band: 900 MHz ISM Band
• Number of RF Bands: 12

EchoPlus® Wireless Junction Box (8-channels)

• Frequency Band: 900 MHz ISM Band
• Number of RF Bands: 12
• RMS Velocity Frequency Range: (±3dB) 4 to 2300 Hz
• Velocity Range: 4.096 ips
• RMS Acceleration Frequency Range: (±3dB) 2300 to 15000 Hz
